Adding an external, more powerful air assist is a MUST DO upgrade for your CO2 laser.  There are many guides on how to do this however none of them are specific to a laser which has a Ryxon KT332N Controller.  Larger lasers use different controllers and the controller connections have a different name on them on the KT332N which may confuse some users.

I’m not doing an inclusive build of materials here. This will just cover wiring the solenoid to the controller.

First of all you need a 24volt Solenoid which is Normally Closed.  That means air only spews out when the solenoid is energized electrically from the controller.  So you need:

• Solenoid
• Wire – you can use any wire as long as it will handle 24 volts and about 250 degrees F.  I chose this wire simply because it is jacketed and it is easier and cleaner to route 1 cable, than 2 separate wires.

Also note that the solenoid is non-polarity specific so that means you don’t have to observe polarity at either end however where the wires are connected to the controller you SHOULD follow standard color coding in case you sell the machine or if it catches on fire the fireman will blame your backwards home brew wiring for the cause of the fire 😃

Continue reading →

My K40 (and various other CO2 lasers) does not have a water flow sensor switch on it.   There are folks who put a water flow meter on the outside of their lasers which gives you a visual representation that the water is indeed flowing.  That’s great.  Until you turn your back and the pump fails causing water to stop flowing and your laser tube and power supply go “POOF”.

You would have to watch that flow meter 100% of the time to be safe.

With a water flow sensor switch it kills power to the laser firing circuit if no water flow is detected thus saving your precious CO2 laser tube and power supply.

The switch in the flow sensor is in the normally open position.  That means the circuit is BROKEN until water flows through the sensor and then the switch closes which ENERGIZES the laser firing circuit.

In fact laser power supplies have a protection circuit ready to roll.

BUT LOOK AT HOW THEY BYPASS THIS CIRCUIT IF THERE IS NO WATER FLOW SENSOR SWITCH INSTALLED!

Bypassing the Water Protection Circuit On A CO2 Laser

Yikes.  The jumper, if it could talk would say……”there is a protection circuit here, and it is working just fine”.  But if your pump fails it would also say…….”there is a protection circuit here, and it is working just fine”.  NO PROTECTION.  THIS IS UNSAFE!

Continue reading →

I hate to beat the proverbial dead horse but I digress.

First I have got to say that anyone ABSOLUTELY HAS THE RIGHT TO BUY A CO2 Laser for their business or hobby or whatever.  I am not opposed to that at all.  More power to ya.  Seems since this COVID pandemic the “work from home” DIY business model has exploded and CO2 lasers are at the forefront of this.  Heck, it is hard to buy a laser right now.

Also let me throw in that while this blog is largely about a lack of technical prowess just know that I am jealous AF of the artistic and creative ability of a lot of you.  I can fix some stuff……but art……..I failed art and I didn’t even take it, and still failed it.  I can’t draw a circle with a compass and a can of beans.

What bothers me when I peruse the forums Facebook groups for CO2 lasers there are a rash of new users with no experience whatsoever on the technical aspects of a CO2 laser.  And let me add…….THAT INCLUDED ME AT ONE TIME.   Again, if you want a laser and can afford one………get one.

Here’s what worries me.  I will frequently see discussions where the new user buys a giant laser and says “What do I do now?”

I’m not knocking you if you are asking that question or any other.  That’s what forums are for.  You are most assuredly doing the right thing.   Just know that I’m scared for you.

The answer I can best provide is “Don’t Kill Yourself”.  First and foremost, know that your CO2 laser uses a High Voltage Flyback transformer that pulses anywhere from 1000 volts DC to about 20,000 volts DC.   Allow me to translate:  That will stop your heart in an ……errrr…….heartbeat.   We’ve all been shocked by household current.  You get tingled, a moment of OUCH and then a giggle.   If you take a 1000vdc shot to your body you will likely die and you better hope you are standing next to someone who knows CPR.  I wish I was joking.  I’m not joking.

Continue reading →

Replacing Crap Water Flow Sensor

CO2 lasers are water cooled.  If the cool water stops flowing the laser tube will die.  That’s all there is to it.   To prevent the laser from firing when there is no water flowing most lasers incorporate some kind of switch that chops power to the laser circuit when no water flow is detected.  We need a good quality water flow sensor.

My new 50 watt laser has such a switch but forums are FULL of reports of failures and especially the fact that the switch will begin leaking.

Crap Water Flow Sensor

While this may not be the exact switch, it is darn similar. There is no outlet port on these things.  The switch is hooked to a Y valve.  One side is inlet, the other is inlet flow and the top opening goes to the switch.

In my mind that doesn’t really measure “Flow”, rather the fact there is water pressure present on the switch.

Let’s say you had a fancy water chiller and the chiller was setting up higher than the laser.   Gravity and shit, would put head pressure on the switch allowing it to fire EVEN WHEN THERE WAS NO FLOW.  I’ve seen several reports of this already.  That renders this switch USELESS.  And again, even if it is working right I’ve also read MANY reports of “this failed after a month” or “this started leaking right away”.
